CASE STUDIES
Heat Network Energy Saving (HNES)
Optimising Heat Network Performance for Efficiency and Sustainability
WISE Controls delivered a programme of works across the Clinical Sciences Support Building (CSSB) and Royal Liverpool University Hospital (RLUH) to address underperforming systems, unlock energy savings, and improve the reliability of critical heating and cooling. By restoring functionality to the ground source heat pump system, validating metering, and implementing smarter control strategies, we were able to deliver significant reductions in wasted energy while enhancing system resilience.
The Challenge
The hospital’s ground source heat pump system had lost communication with the BMS and was not fulfilling its role as the primary source of heating and cooling. In addition, inaccuracies in metering and fixed setpoint strategies were leading to inefficiencies across the wider heat network. Estates teams needed a long-term solution that would restore system performance and reduce rising energy costs.
The Solution
Our engineers carried out a detailed investigation and implemented a bespoke integration plan:
Restored full communication and control of the IFTECH ground source system by installing missing field wiring and reconfiguring software.
Re-engineered BMS integration points for reliable monitoring and alarm visibility.
Validated and corrected steam, heat, and coolth metering to improve accuracy and remove false data.
Developed a new weather-compensated control strategy for steam plate heat exchangers to scale heating setpoints based on outside temperature.
“WISE Controls worked with us to reduce energy on site and improve control. Phil and Mia are great, very dedicated and always trying to understand where improvements can be done, absolutely sustainability minded and very knowledgeable.”
— R.Q. Carbon & Energy Manager, LUHFT
Key Outcomes
-
20% of heating and cooling load now met by the ground source system
4% energy savings through improved metering accuracy
15% reduction in steam consumption from control strategy optimisation
-
Significant reduction in reliance on steam-based systems
Long-term operational savings from reduced energy waste and improved asset lifespan
-
Restored reliable communication between BMS and ground source system
Enhanced monitoring with alarms for faster fault detection
Reduced risk of downtime for critical heating and IT cooling systems
-
Optimised ground source heating supply temperature: 41.0°C
Optimised cooling supply temperature: 13.5°C
Full integration with BMS for real-time monitoring and alarms
-
More reliable heating and cooling across CSSB and IT hub rooms
Greater system resilience, reducing risk of service disruption
Supports hospital sustainability and carbon reduction goals
The Result
The project successfully restored the IFTECH ground source system, now delivering 20% of the building’s heating and cooling load while cutting reliance on traditional steam systems. With an additional 15% reduction in steam consumption and improved metering accuracy delivering 4% energy savings, the hospital now benefits from a more efficient, resilient, and sustainable heat network.
